■ Product Brief
The Multi Lane Stickpack Checkweigher is an automated dynamic weighing system designed for high-speed stick pack, sachet, and small pouch production lines. It combines multi-lane weight inspection with an inclined conveyor, providing stable product transfer and continuous online checkweighing where floor space, conveyor height, or production-line layout requires an inclined configuration.
The 10 Lane Checkweigher can simultaneously inspect multiple lanes of stick packs and identify products that are underweight, overweight, or outside preset weight tolerances. Non-conforming products can be automatically rejected, helping manufacturers maintain consistent product weight and reduce product giveaway.
■ Technical Data
| Type | SG-10X |
| Weighing scope | 2-300g |
| Restrictions of product | L:180 W:40 H:2-20(mm) |
| Accuracy | ±0.01g (Depends on products) |
| Division scale | 0.01g |
| Belt width | 30mm |
| Max Speed | 70 pcs/min(one lane) |
| Weight of machine | about 200Kg |
| Powder supply | AC220V 50HZ |
| Power | about 600W |
| Main material | SUS304/316(Stainless Steel) |
■ Product Highlights
1.Multi-Lane Weighing – Simultaneously checks multiple stick packs for higher production efficiency.
2.Dynamic Online Checkweighing – Performs real-time weight inspection without stopping the production line.
3.Inclined Conveyor Design – Suitable for production lines requiring elevated or angled product transfer.
4.Independent Lane Control – Each weighing lane can be configured and monitored independently.
5.Automatic Reject System – Automatically removes underweight and overweight stick packs according to preset limits.
6.High-Precision Weighing Sensors – Provides stable and repeatable weight measurements for lightweight packages.
7.Touchscreen HMI – Convenient setting of target weight, tolerance limits, product parameters, and inspection data.
8.Real-Time Weight Monitoring – Displays production quantity, qualified products, rejected products, and weight information.
10.Stainless Steel Construction – Suitable for demanding food, pharmaceutical, nutraceutical, and chemical packaging environments.
11.Flexible Line Integration – Can be connected with multi-lane filling, sealing, conveying, counting, labeling, and other packaging equipment.
12.Customizable Lane Configuration – The number of lanes, conveyor dimensions, height, angle, and rejection method can be customized according to the application.
■ Industry Applications
■ Company Profile
■ Cooperative Clients
■ Exhibition
■ Package & Logistics
Our machines is fully tested and calibrated before delivery.
It is packed in a strong wooden case with internal shockproof protection.
Various shipping options are available — by sea, air, or land — ensuring safe and on-time delivery by professional logistics partners.
