Food Production Line Automatic Conveyor Belt Metal Detector Machine

If you are interested in my products,please contact me! Whatsapp:+86 18302121916


Product Summarize

Food Production Line Automatic Metal Detector Machine uses advanced digital processing technology to simultaneously detect magnetic and non-magnetic metals in products. Color touch screen facilitates human-computer interaction. The detection sensitivity is high and the stability is good.Conveyor Belt Metal Detector Machine has a variety of rejection devices to choose from to avoid residual metal in products during production.

Conveyor Belt Metal Detector Machine

Product Parameter

Model: SG-JS150
Detection hole width: 150mm
Detection hole height: 100-200mm
Detection sensitivity:
H-100mm: Fe≥Φ0.8mm,SUS≥Φ1.2mm
H-120mm: Fe≥Φ0.8mm,SUS≥Φ1.8mm
H-150mm: Fe≥Φ1.2mm,SUS≥Φ2.0mm
H-200mm: Fe≥Φ1.5mm,SUS≥Φ2.5mm
Effective detection hole width: 150mm
Effective detection hole height: 100-200mm
Weighing range: 5-500g
Weighing accuracy: ±0.1g(Depends on products)
Conveyor belt height: 750mm (±50mm)
Conveying capacity: 10Kg/time
Delivery direction: from left to right
Maximum speed of conveyor belt: 25m/min
Conveyor belt material: food grade PU belt
Protection class: IP65
Display and operation mode: LED LCD flat button input
Machine weight: 240kg
Power requirements: AC220V 50HZ
Power: 300W
Dimensions: about L2267×W589×H1500mm (final design shall prevail)

Automatic Metal Detector Machine

Product Characteristics

1. Function: Set various required functions and modes, and set up self-test function.
2. Sensitivity: divided into gears, adjustable to increase or decrease.
3. The sensitivity of the electric frequency display can be adjusted to reflect the metal index.
5. When trace amounts of metal are detected, sound, light, and instruments will alarm at the same time, and unqualified products will automatically stop.
6. It has a self-checking function. You can check whether the instrument is normal by yourself to avoid unnecessary maintenance.
7. The whole machine is made of industrial stainless steel, which is waterproof and rust-proof. It is hygienic and easy to clean.
8. The conveyor belt is environmentally friendly. Food-grade conveyor belt, suitable for temperatures ranging from -20C to 65C, making it easy to work in the refrigerated area.
9. Combined with a miniature subwoofer environmentally friendly motor, there will be no faults in continuous use.
10. It has leakage insurance function and high insurance coefficient.
11. If it contains aluminum foil or coated film packaging, it is appropriate to inspect it before packaging.


Food Production Line Metal Detector Machine

Specific Application

Company Profile

Customer Visit



1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.

After Sale Service

1.Product quality commitment
(1).There are quality records and testing data for the manufacture and testing of products.
(2).For the inspection of product performance,we sincerely invite users to inspect the whole process and performance of the product in person.After the product is confirmed to be qualified,it will be packaged and shipped.
2.the product price commitment
Under the same competitive conditions, our company will sincerely provide you with a preferential price on the basis of not reducing the technical performance of the product or changing the product components.
3. Delivery time commitment
Product delivery time: as far as possible according to user requirements,if there are special requirements, it needs to be completed in advance,and strive to meet user needs.
