Product Overview
Advanced 0.4mm High Sensitivity Tablet Pipeline Metal Detector is a specific type of metal detector designed to inspect pharmaceutical products for any metal contaminants.These contaminants can be accidentally introduced during the manufacturing process and pose a serious health risk to consumers.It is vital for ensuring the safety and quality of tablets and capsules.
Metal Detector Machine for Capsule Pill typically use a process called electromagnetic induction.The machine generates an electromagnetic field around a coil.When a capsule or tablet containing metal enters the field,eddy currents are created in the metal.These eddy currents create their own opposing electromagnetic field,which is detected by the machine.The machine then triggers an alarm or rejection mechanism to remove the contaminated product from the production line.
Product Parameter
SG-YJ60
Feed port height and size: Height: 770-930mm Feed port size: 76mm
Height and size of outlet: Height: 770-860mm Size of outlet: 51mm
Effective passing size: W70*H20mm
Maximum production capacity: 500,000 pcs/hour
Detection sensitivity: Fe: 0.4mm, stainless steel: 0.6mm
Machine weight: 75kg
Removal method: flip culling
Working voltage: 220V/110V, 50/60HZ
Equipment dimensions: 1115*550 (1280-1400) mm
For reference only, please consult for details!
Contact us to recommend a product that is suitable for you!
Standard Features
1.Suitable for detecting and separating magnetic and non-magnetic metals in tablets and capsules.
2.It can be used with tablet press machine, capsule filling machine and tablet sieving machine, or used alone, easy to adapt to the site.
3.Elimination method: minimize material loss with electromagnet control flap fast automatic elimination to keep normal production.
4.Simple design, easy to clean.
Specific Application
Tablet Production: Inspecting tablets as they come off the press.
Capsule Filling: Inspecting capsules before they are filled with medication.
