|| Product Introduction
Vitamins Bottle Checkweigher is a specialized inline weighing system for plastic or glass bottles filled with vitamins, supplements, or nutraceuticals.High-Speed Weight Checker ensure each bottle contains the correct weight of tablets, capsules, or gummies before capping/labeling/packing.
|| Tech Specifications
Model:SG-150
Weighing range:5-500g
Minimum scale:0.1g
Checking speed :Max 120pcs/Min
Belt speed:0-65m/min
Box size limit:Length:200mm Width:150mm Height:3-200mm
Operation Way:Touch operation
Conveying direction:Facing the touch screen from left to right
Rejection method:Push Rejection
Belt height from the ground:750±50mm（can be customized）
Machine material:Stainless steel（SUS304）
Power supply:220V50/60HZ
Power:About300W
Feeding conveyor size:316mmX150mm
Weighing conveyor size:316mmX150mm
Rejection conveyor size:510mmX150mm
Weight:About120KG
|| Main Features
1.Reject Mechanism:
Air-jet or pusher for lightweight bottles
Drop gate/diverter for larger bottles
2.Compact Design: Slim frame to integrate between filling and capping machines.
3.Data Tracking: Weight statistics, trend analysis, batch records.
4.Optional Combo: Integrated with metal detector for contaminant detection.
|| Application
Pharmaceuticals & Nutraceuticals: Vitamin tablets, softgels, capsules, gummies.
Food Supplements: Protein pills, herbal capsules.
Healthcare Products: Calcium, fish oil, multivitamin bottles.
|| Our Company
|| Our Customers
|| Our Exhibitions
|| Package & Shipping
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
