■ Product Overview
The Ultralight Small Packet Checkweigher is a high-precision automated device specifically designed for checking the weight of extremely small and lightweight packaged products (such as pharmaceutical powder packets, tea bags, seed packets, electronic components, etc.) to ensure they meet weight standards.
■ Tech Specifications
Model: SG-1X
Weighing range: 0.2-50g
Product restrictions: L:180 W-40 H:2-20(mm)
Sorting accuracy: ±0.01g (Depends on products)
Graduation value: 0.01g
Maximum speed: 40-50 pcs/min
Belt width: 100mm (customizable)
Machine weight: about 80kg
Power supply: AC220V±10%50HZ
Power: about 100W
Main material: SUS304
■ Main Features
1. Feeding and Conveying System
Low-inertia, light-load conveyor belt.
Feed guide rail/small bag positioning device.
Stable and continuous feeding ensures that small bags enter the weighing area gently.
2. Weighing and Detection System (Core)
High-precision load cell.
High-speed sampling controller and weighing algorithm.
Dynamic weighing and comparison with standard weight limits.
3. Rejection Mechanism
Variations include push rod, air blower, side blower, and small pusher plate.
Automatic rejection of non-conforming weights ensures product quality.
4. Human-Machine Interface (HMI) and Control System
Touchscreen displays weight, statistical data, and alarm information.
Supports parameter setting, data export, and production records.
5. Support Frame and Safety Protection
Shockproof and disturbance-resistant frame.
Safety cover and emergency stop button ensure equipment safety.
■ Application
Pharmaceutical Industry: Weight checking of small packages of granules, powders, and effervescent powders (to prevent empty packages or insufficient filling).
Fine Chemicals: Reagent packets, high-end desiccants.
Food Industry: Premium tea bags, probiotic powder packets.
Electronics/Manufacturing: Packaging of miniature precision components, expensive metal excipients.
■ Customers
■ Exhibitions
■ Packaging & Delivery
Our machines is fully tested and calibrated before delivery.
It is packed in a strong wooden case with internal shockproof protection.
Various shipping options are available — by sea, air, or land — ensuring safe and on-time delivery by professional logistics partners.
