|| Product Introduction
Capsule & Tablet Weighing and Sorting Machine is an automated system used primarily in pharmaceutical, nutraceutical, and supplement manufacturing to ensure each capsule or tablet meets precise weight specifications and sort out underweight/overweight capsule.
High-Speed Checckweigher – SG-JN10
|| Tech Specifications
Max throughput (10 lanes)100000 capsules/h
Max throughput (20 lanes)200,000 capsules/h
Max throughput (30 lanes)300,000 capsules/h
Weigh range:2-2000 mg
Highest sorting accuracy:±0.5mg
Scale interval:0.1 mg
Product size : Capsule No. 000 to 5.
Weight of Machine :350kg/500kg/700kg
Power supply:AC-220V±10%, 50HZ
Compressed air:0.3-0.9Mpa
|| Main Features
1.Ultra-High Precision: Milligram (mg) resolution load cells capable of handling small, lightweight products.
2.Gentle Handling: Mechanisms designed to minimize damage to fragile capsules or coated tablets.
3.Anti-Static Design: Prevents lightweight capsules from sticking to surfaces.
4.Dust Protection: Sealed electronics and easy-clean surfaces for hygienic environments.
5.Product-Specific Tooling: Customizable guides, lanes, and reject mechanisms for different shapes/sizes.
6.User-Friendly Interface: Easy setup (recipe management), clear displays, and comprehensive reporting.
|| Application
Industries That Use Capsule Checkweighers:
Pharmaceuticals (tablets, hard/soft gelatin capsules)
Nutraceuticals & Supplements (vitamins, herbal capsules)
Cosmetics & Health Products (gelcap-based products)
|| Our Company
|| Our Customers
|| Our Exhibitions
|| Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
