■ Product Introduction
Dynamic Conveyor Belt Bags Weighing Machine is an industrial weighing device used to measure the weight of pre-packaged bags in production lines.Pouch Checkweigher ensures that each bag meets the specified weight requirements, helping manufacturers comply with trade regulations, reduce giveaway, and maintain quality control.
■ Tech Specifications
Model:SG-150
Weighing range:5-500g
Minimum scale:0.1g
Checking speed :Max 120pcs/Min
Belt speed:0-65m/min
Box size limit:Length:200mm Width:150mm Height:3-200mm
Operation Way:Touch operation
Conveying direction:Facing the touch screen from left to right
Rejection method:Push Rejection
Belt height from the ground:750±50mm（can be customized）
Machine material:Stainless steel（SUS304）
Power supply:220V50/60HZ
Power:About300W
■ Main Features
1. Automatic weighing: quickly detect the weight of a single package to determine whether it is within the qualified range.
2. Weight sorting: automatically remove overweight or underweight unqualified products (such as by air blowing, push rods, etc.).
3. Data statistics: record production data and generate reports to facilitate quality traceability and analysis.
4. High-precision detection: The accuracy can reach up to ±0.1g, depending on the product type.
■ Application
■ Company
■ Customers
■ Exhibitions
■ Package & Shipping
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
