Capsules Pills Tablets Automatic Professional Grade Check Weigher Machine

If you're interested in our products,please contact us! WhatsApp:+86 18302121916


Product Introduction

Shanghai Shigan Industrial Co., Ltd. specializes in the development and production of Capsules Pills Tablets Automatic Check Weigher Machine,with a maximum detection accuracy of ±0.5mg. It uses an industrial computer color touch screen to reasonably set the upper and lower limits for capsule rejection.Professional Grade Check Weigher Machine uses a high-speed weighing module and check-weighing algorithm software to quickly make qualified judgments and accurately reject unqualified capsules at high speed.

Professional Grade Check Weigher Machine
Technical Parameters

Weighing scope :5-2000mg
Display scale:0.1mg
Highest sorting accuracy:±0.5mg
Product specification:Capsule-00#-5#/Wafer-Φ5.5-Φ18mm/Thickness-3-12mm/Pill-Φ5.5-Φ12mm(Other sizes or shapes subject to testing)
Highest sorting ability :75000 PCS/HR/150000 PCS/HR/230000 PCS/HR
Number of columns:10 Columns/20 Columns/30 Columns
Power supply:AC-220V±10%, 50HZ
Compressed air:0.3-0.9Mpa
Use environment:15~30°C (The temperature change during use should not exceed the range of 1°C/h.Hunidity:30-70%(but no condensation)
Weight of Machine :350kg/500kg/700kg
Shell material:SUS304
You can select the best suitable model depending on the production volume.

Automatic Check Weigher Machine
Main Features

◎Large screen display clear viewing and convenient operation.
◎Chinese-English interface( Multple languages can be customized).
◎Suitable for regular capsules and tablets
◎It can actually display the relevant data of eachchannel
◎Three-level operation authority management support se lf-set passwora.
◎100 kinds data can store with strong data statistics function.
◎All channels can be cleaned without disassembly.
◎Multi-channel passing products to improve production efficiency (the number of channels can be customized).
You can select the best suitable model depending on the production volume.

Capsules Pills Tablets Check Weigher Machine

Our Company


Our Customers


Our Exhibitions

Package & Shipping

1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.

After Sale Service

project design,performance introduction,technical agreement,contract signing,production testing and we can customized production according to your requirements.
we will provide you with the latest process in the product assembly,packing and transportation.
◎We provide videos and instruction manual to show the process of installation.
◎We provide training for installation for free in our factory.
◎We can send technician to buyer’s factory to install the machine and provide training service.
◎ For our machines, we will provide some spare parts and easy broken parts free of charge when delivering.
◎We will have one year free warranty period. During warranty period, if there is any malfunction for the machine, we will try our best to solve the problem within 24 hours. If there are some spare parts needed to be replaced, we will provide the spare parts for free. Beyond warranty, we will charge the cost price for spare parts.
